R-300C Desktop Dispensing Robot
Standard desktop 3-axis dispensing platform capable of dispensing along linear and circular paths; easy to operate thanks to the teach pendant design; works well with AB glue equipment for automated production needs.
Economic automatic dispensing equipment driven by 3-axis micro-stepping motors and equipped with teaching pendant control; suitable for dispensing on small objects; can be combined with injection syringe or dispensing valve for one-component dispenser.
*Suitable materials: epoxy, silicone, PU glue, UV glue, lubricant, soldering flux, soldering paste, red / black glue, screw fixing agent, anaerobic glue, and many more.
Standard desktop 3-axis robotic arm for effective improvement of production; the automatic metering and dispensing equipment is driven by stepping motor for mechanical transmission and positioning and can be combined with AB glue equipment; high precision; advanced functions, such as visual positioning or laser detection, are available as options.
| Model | R-300C |
| X/Y/Z mm | 300 / 300 / 100 |
| Worktable / Tool | 10.0kg / 5.0kg |
| X&Y/Z (mm/sec) | 800/320 |
| Repeatability | ±0.02mm/Axis |
| Resolution | 0.01 mm/Axis |
| Memory Capacity | >100 group~4000points/group |
| Memory Storage | CF card, Teach Pendant, PC Storage |
| CPU | 32 Bit |
| Monitor | Teach Pendant LCD, VGA port for optional monitor |
| Motor | 5-Phase |
| Interpolation | PTP & CP |
| Route | 3 axes 3D route |
| Teaching Method | Teaching Pendant or PC |
| I/O Signal | 8 Inputs / 8 Outputs |
| External Control | RS232 |
| Power Input | AC100-230V 330W |
| Working Temperature | 5-40℃ |
| Relative Humidity | 20-90% condensation |
| Size W x D x H (mm) | 490 x 500 x 600 |
| Weight | 40kg |
